RODUCT NAME |
||||||
|
ICF CP2502 |
||||||
|
FUNCTIONAL DESCRIPTION |
||||||
|
Ev 8 LED Charging Display Circuit |
||||||
|
APPLICATIONS |
||||||
|
Electric vehicle Charger |
||||||
|
GENERAL DESCRIPTION |
||||||
|
ICF CP2502 is electric vehicle 8 LED charging power disply circuit,it has the function of under voltage indication and charging stage indication. |
||||||
|
FEATURES |
||||||
|
Suitable for under voltage in 42V,full charge in 48V Power ground reverse protection By changing and adjusting the state of 6 and 7 feet,the under voltage point can be adjusted. Low power consumption 1.4mA |
||||||
|
BLOCK DIAGRAM |
||||||
|
|
||||||
|
ORDERING INFORMATION |
||||||
|
